Some reds feel flat once reflections are softened. Passion Red (SCH01) keeps its depth, pairing a dark, warm red base with a restrained matte chrome surface.

Key Attributes

Matte Chrome Finish: Soft reflections let the red stay rich without the glare of a bright chrome wrap. Hybrid Construction: Polymeric hybrid film with a silver coating gives the color its metal-like foundation across body panels. Controlled

Application

Air-release channels help installers work trapped air out while positioning the film on large sections. Reliable Adhesion: Henkel solvent-based acrylic adhesive supports a secure bond and clean heat removal within 1 year of installation. Directional Surface: Consistent panel orientation keeps the matte chrome appearance flowing in one direction across the vehicle. Passion Red starts with a deep red that carries a slight warm undertone. The matte chrome layer softens the shine, yet the curved sample still shows lighter ruby-red highlights against darker sections. It feels richer than a plain solid red, but it does not cross into dark burgundy. That balance keeps the color full and clearly red.

OEM Match

Closest to Mazda Soul Red Crystal Metallic, with a softer matte chrome expression. Darker and slightly warmer than Audi Misano Red Pearl Effect. Lighter and redder than Mazda Artisan Red Premium Metallic. Passion Red brings this layered red direction to vehicles that were never offered in these factory colors, while keeping its own muted metal finish.

Film Construction

• Film Type: Premium polymeric hybrid vinyl film with air-release channels and Matte finish
• Film Thickness: 0.11 mm
• Release Liner: silicone-coated release liner
• Adhesive: Henkel solvent-based acrylic, ultra-weather-resistant, 12 um dry
• Roll Width: 5 ft (1.52 m)
• Full Roll Length: 59 ft (18 m)

Performance

• Service temperature: -30°C to +45°C
• Release force: 0.18 N/25mm (standard 0.10-0.30)
• Initial tack: 1015 g/25mm (standard 800-1500)
• Peel strength (180°): 8.1 N/25mm (standard >=4.9)
• Adhesion strength: 70 (standard >=60, no shifting)
• Aging tested: high and low temperature release without adhesive residue
• Storage shelf life: 2 years at +10°C to +20°C, 50% RH, dry conditions, away from sunlight

Warranty

• Built for long-term outdoor use, commonly up to 3 years on vertical panels and around 2 years across a full wrap depending on climate and maintenance.

• Application temperature: +17°C to +23°C
• Tools: squeegee with buffer, knife, masking tape, heat gun, magnets, gloves, IR thermometer
• Conformability: smooth and medium-curved surfaces
• Post-heat: 90-100°C
• Cure: 24 hrs above 10°C; 48 hrs at room temperature recommended
• Overlap: 3-4 mm
• Directional film: align panels in the same direction during installation.
• Clean, degrease, and dry the surface before installation.
• Remove the protective cap or PET protective layer before applying heat.
• Aftercare: use pH-neutral products and avoid hot wax or strong solvents.

TeckWrap statements, technical information, and recommendations are based on product testing believed to be reliable, but they do not guarantee identical results in every installation environment. The buyer should confirm suitability for the intended vehicle and use.

Screen images may vary from the physical film. Always check a real color swatch before ordering, and use rolls from the same production LOT for full-wrap color consistency.

Film performance depends on storage, surface preparation, installation method, climate, and maintenance. Scratches during installation or daily use, labor, transportation, and consequential damages are not covered by standard product warranty.
